SBR30A60CTB
Document number: DS31529 Rev. 5 - 2
2 of 4
www.diodes.com
July 2011
? Diodes Incorporated
SBR30A60CTB
SBR is a registered trademark of Diodes Incorporated.
Maximum Ratings (Per Leg)
@TA
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol Value Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
VRRM
VRWM
VRM
60 V
Average Rectified Output Current (Per Leg)
(Total)
IO
15
30
A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
IFSM
180 A
Thermal Characteristics
(Per Leg)
Characteristic Symbol Value Unit
Maximum Thermal Resistance Junction to Case
RθJC
2 °C/W
Operating and Storage Temperature Range
TJ, TSTG
-65 to +150
oC
Electrical Characteristics (Per Leg) @TA
= 25°C unless otherwise specified
Characteristic Symbol Min Typ Max Unit Test Condition
Forward Voltage Drop (per leg)
VF
-
0.56
-
0.63
0.60
V
IF
= 15A, T
J
= 25oC
IF
= 15A, T
J
= 125oC
Leakage Current (Note 4)
IR
-
-
-
0.5
100
mA
VR
= 60V, T
J
= 25oC
VR
= 60V, T
J
= 125oC
Notes: 4. Short duration pulse test used
to minimize self-heating effect.
0
0255075100125150
10
R = 16°C/WθJA
20
30
I AVERAGE FORWARD CURRENT (A)
F(AV),
T , AMBIENT TEMPERATURE ( C)A
°
Fig. 1 Forward Current Derating Curve
Per Element
R = RθθJA JC
Total Device
R = RθθJA JC
Per Element
25
15
5
0.0001
0 200 400 600 800
0.001
0.01
0.1
1
10
100
Fig. 2 Typical Forward Characteristics
V , INSTANTANEOUS FORWARD VOLTAGE (mV)F
I , INSTANTANEOUS FORWARD CURRENT (A)
F
